KK1200A—3000A 平板型快速晶闸管

Type

VDRM
VRRM

IT(AV)

@85℃

tq

@100℃

30V/μS

VTM

@ITM

(max)

IGT

VGT

IDRM
IRRM

(max)

IH

(max)

Tjm

ITSM

@10ms

I2t

@10ms

dv/dt

(min)

di/dt

(min)

Rthjc

(max)

外形

(V)

(A)

(μS)

(V/A)

(mA)

(V)

(mA)

(mA)

℃

(KA)

(KA2S)

(V/μS)

(A/μS)

(℃/W)

KK1200-55KT14

800-1800

1200

15-35

3.1/3000

40-300

0.9-2.5

60

20-400

115

14

980

500

300

0.024

KT14

KK1500-60KT15

1200-2600

1500

20-60

3.1/3000

40-300

0.9-3.0

60

20-500

115

16

1300

500

300

0.02

KT15

KK1800-67KT9B

1200-2600

1800

15-60

3.1/4000

40-300

0.9-3.0

60

20-500

115

19

1800

500

300

0.017

KT9B

KK2000-70KT16

1200-2600

2000

15-60

3.1/4000

40-350

0.9-3.0

80

20-800

115

21

2200

500

300

0.016

KT16

KK2500-76KT17

1200-2600

2500

15-60

3.1/5000

40-350

0.9-3.0

80

20-800

115

27

3600

500

300

0.011

KT17

KK3000-76KT17

800-1600

3000

20-60

3.1/5000

40-350

0.9-3.0

80

20-800

115

31

4800

500

300

0.011

KT17
